選型參考表Selection reference table
|
機 型 Model |
拉 簧 Tension Spring |
參考線徑(mm) Wire Diameter |
張力范圍(g.f) Tension Scope |
張力桿 Tension Arm |
標準配置 Standard Set |
||
| SETC-100-BR/BRD | S2 | Φ0.03-Φ0.06 | 10-25 | SA2 |
張力桿SA2/SA3 拉簧S2/S3/S4 |
||
| S3 | Φ0.05-Φ0.09 | 22-65 | SA3 | ||||
| S4 | Φ0.08-Φ0.14 | 60-100 | SA3 | ||||
| SETC-200-BR/BRD | S2 | Φ0.03-Φ0.06 | 10-25 | SA2 |
張力桿SA2/SA3 拉簧S2/S3/S4/S5 |
||
| S3 | Φ0.05-Φ0.09 | 22-65 | SA3 | ||||
| S4 | Φ0.08-Φ0.14 | 60-150 | SA3 | ||||
| S5 | Φ0.14-Φ0.18 | 140-200 | SA3 | ||||
| SETC-300-BR/BRD | S2 | Φ0.03-Φ0.06 | 10-25 | SA3 |
張力桿SA3/SA4 拉簧S2/S3/S4/S5 |
||
| S3 | Φ0.05-Φ0.09 | 22-65 | SA3 | ||||
| S4 | Φ0.08-Φ0.14 | 60-150 | SA4 | ||||
| S5 | Φ0.14-Φ0.22 | 140-300 | SA4 | ||||
| SETC-600-BR/BRD | S3 | Φ0.05-Φ0.09 | 22-65 | SA4 |
張力桿SA4/Sa5 拉簧S3/S4/S5/S6 |
||
| S4 | Φ0.08-Φ0.14 | 60-150 | SA4 | ||||
| S5 | Φ0.14-Φ0.22 | 140-360 | SA5 | ||||
| S6 | Φ0.22-Φ0.35 | 350-600 | SA5 | ||||
| SETC-1000-BR/BRD | S4 | Φ0.08-Φ0.14 | 60-150 | SA4 |
張力桿SA4/SA5-2 拉簧S4/S5/S6/SS7/SS7-1/SS7-2 |
||
| S5 | Φ0.14-Φ0.22 | 140-360 | SA4 | ||||
| SS6 | Φ0.22-Φ0.35 | 350-800 | SA4 | ||||
| SS7 | Φ0.18-Φ0.35 | 200-700 | SA4 | ||||
| SS7-1 | Φ0.25-Φ0.45 | 400-1000 | SA5-2 | ||||
| SS7-2 | Φ0.25-Φ0.45 | 400-1000 | SA5-2 | ||||
